| PMDC MOTOR Technical Data | ||||||||
|---|---|---|---|---|---|---|---|---|
| Model | Eccentric Size | Voltage (V) | Rated | Stall | ||||
| Operating Range | Nominal | Start | Speed (RPM) | Current (mA) | Current (mA) | |||
| SL-DN20-08250 | R5.8*4.8 | 3.0~5.0 | 4VDC | 1.2VDC | 7600 | 110 | 380 | |
| SL-DN20-08200 | R5.8*3.6 | 3.0~5.0 | 3.7VDC | 0.8VDC | 8500 | 130 | 480 | |
| SL-DN20-12110 | R5.8*6.0 | 1.5~3.0 | 2.4VDC | 0.8VDC | 9100 | 330 | 1100 | |
| SL-DN20-10145 | R5.8*2.4 | 1.5~4.0 | 3VDC | 0.6VDC | 10600 | 160 | 700 | |
Specializing in motor production for more than 14 years with three dedicated factories. Our professional R&D team and experienced engineers ensure a superior product experience.
Rigorous quality checks from raw material receipt to final shipment. We utilize advanced testing equipment including Hardness Testers, 2.5D Image Testers, and Salt Spray Chambers.
Gold seller status with high credibility in the industry.
100% on-time delivery rate to ensure your project stays on schedule.
Fast sampling: Standard samples within 2 weeks, customized samples within 3 weeks.
Highly responsive communication with replies typically within 2 hours.
