SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

📋 Product Description

Model		Rated Voltage (V)		No-Load		Rated				Stall
Series	Sub-model	Range	Nominal	Speed (RPM)	Current (mA)	Speed (RPM)	Current (mA)	Torque (mN.m)	Power (W)	Current (mA)	Torque (mN.m)
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98	0.1	260	4.02
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4	1.71	2550	17
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2	11.51	24000	55
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8	5.17	3800	37.5

📌 Technical Note: Please refer to the specific model parameters for precision applications. Performance values may vary based on load conditions.

🚀 Application

What is the operating voltage range for the SRC-370SH-4730?

The nominal voltage is 4.5V DC, with an operating range typically between 3.0V and 5.0V.

What is the maximum no-load speed of this motor?

The motor reaches a high-speed performance of approximately 17,500 RPM under no-load conditions.

Is this motor suitable for high-torque applications?

Yes, it provides a rated torque of 7.2 mN.m and a stall torque up to 55 mN.m, making it efficient for various micro-mechanical tasks.

What are common applications for the 370 series PMDC motors?

These motors are widely used in household appliances, security systems, electronic toys, and precision automotive components.

How does the 4730 model compare to the 18139 model?

The 4730 model is designed for lower voltage (4.5V) and higher RPM, while the 18139 operates at 12V with a more moderate speed profile.

Can the shaft length or technical data be customized?

As a factory-standard item, common variations exist within the series (RF and RC types) to meet different mechanical integration requirements.
